ACE Inhibitory Activity Assay

  • Colorimetric Microplate Assay Possible
  • Possible to Test Multiple Samples at One Time
  • Simple Protocol
  • No Harmful Organic Solvent Required
    • Product code
      A502  ACE Kit - WST
    Unit size Price Item Code
    50 tests $497.00 A502-05
    100 tests $811.00 A502-10


    Quantity may be adjusted within the cart.
    50 tests ・Substrate Buffer
    ・Enzyme A
    ・Enzyme B
    ・Enzyme C
    ・Indicator Solution
    1 ml x1
    5 ml x1
    100 tests ・Substrate Buffer
    ・Enzyme A
    ・Enzyme B
    ・Enzyme C
    ・Indicator Solution
    1 ml x2
    5 ml x2


The kit is used for the determination of ACE inhibition activity. ACE works in the Renin-Angiotensin system, which is one of the mechanisms of blood pressure control, to convert Angiotensin I to the vasopressor Angiotensin II. This enzyme also contributes to elevated blood pressure due to its role in breaking down the antihypertensive peptide Bradykinin. In recent years, food and supplements containing ingredients that block ACE have received attention for their use in preventing high blood pressure. The conventional method of measuring ACE inhibition employs the synthetic substrate Hippuryl-His-Leu. Hippuric acid from the synthetic substrate is extracted with ethyl acetate, condensed, redissolved, and then read at an absorbance of 228 nm. This method is cumbersome and measurement is subjected to error due to residual ethyl acetate. ACE inhibition Assay Kit enzymatically detects 3-Hydroxybutyric acid (3HB), which is made from 3-Hydryoxybutyryl-Gly-Gly-Gly (3HB-GGG). Using a 96-well format, it is possible to test multiple samples at one time. In addition, there is no need to use harmful organic solvents, resulting in a safe, simple, and highly reproducible assay.

Fig. 1 Principle of the assay system to determine ACE activity or inhibition activity.


Technical info

plate reader with 450 nm filter; 96-well culture plate, 2-20 μl, 20-200 μl, 100-1000 μl and multi-channel pipettes; 37ºC incubator, Disposable syringe (1 ml)

Required Equipment and Materials

Comparison to the Conventional Method by Ethyl Acetate

Example Assay Data

Fig. 2 Inhibition curves prepared by Alacepril and Captopril.
IC50 of Alacepril and Captopril are 3.62 μM and 2.14 nM, respectively. Both compounds are ACE inhibitors.

Fig. 3 Inhibition curves prepared by two beverages containing a valyltyrosine (pink) or lacto tripeptide (blue) .
IC50 of these beverages are 0.56% and 0.69%, respectively. It is known that these substances have antihypertensive effects. *Concentration of the beverage in the sample solution.

Checking the Presence of ACE Inhibition

ACE inhibitions is present in the sample if absorbance of the sample (Total sample AU – Blank 2 AU) is lower than Blank 1 (Total Blank 1 AU – Blank 2 AU).

For 50 tests unit size, 14 samples can be tested in triplicate

Protocol: Presence of ACE Inhibition

Determination of IC50 (50% inhibitory concentration)

Prepare an inhibit ion curve using the sample concentration for X axis and the ACE inhibitory activity for Y axis. A typical inhibition curve is shown in Fig. 4.
Determine the concentration of the sample solution that gives 50% ACE inhibitory activity as indicated in Fig. 4 .

For 50 tests unit size, 2 samples can be tested in triplicate

Protocol: Determination of IC50

The Potential of ACE Kit-WST in Discovery of Angiotensin-Converting Enzyme (ACE) Inhibitors to Suppress Inflammation after Viral Infection (COVID-19)

ACE Kit-WST is expected to be an advantageous tool to support the discovery of ACE inhibitors effective at suppressing inflammation after SARS-CoV-2 infection.

Angiotensin-converting enzyme (ACE) produces angiotensin II (Ang II), a vasoconstrictor, from the C-terminus of angiotensin I (Ang I), which has almost no biological activity. ACE and Ang II activity is countered by ACE2, which functions to cleave inflammatory Ang II into non-inflammatory peptide Ang 1-7.

During SARS-CoV-2 infection, angiotensin-converting enzyme 2 (ACE2) from the cell membrane is taken up into cells along with the virus, decreasing ACE2 activity on the cell membrane. As a result, angiotensin II (Ang II), which had been counteracted by ACE2, becomes uninhibited, beginning a cascade towards an inflammatory cytokine storm that has been suggested to promote lung damage.

Thus, Ang-II mediated cytokine storm is considered to be an important mechanism of severe COVID-19. Therefore, ACE inhibitors, which suppress the Ang II system, are currently expected to reduce the risk of severe Covid-19 symptoms brought on by inflammation, such as acute respiratory distress.


1. Hoffmann M, Kleine-Weber H, Schroeder S, et al., “Sars-cov-2 cell entry depends on ace2 and tmprss2 and is blocked by a clinically proven protease inhibitor”Cell2020, 181, 271-280 e278.
2. Imai Y, Kuba K, Rao S, et al., “Angiotensin-converting enzyme 2 protects from severe acute lung failure” Nature2005, 436, 112-116.
3. Zou Z, Yan Y, Shu Y, et al., “Angiotensin-converting enzyme 2 protects from lethal avian influenza a h5n1 infections”Nat Commun., 2014, 5, 3594.
4. Gu H, Xie Z, Li T, et al., “Angiotensin-converting enzyme 2 inhibits lung injury induced by respiratory syncytial virus”Sci Rep., 2016, 6, 19840.


Open References

No. Sample Reference (Link)
1) Garlic;
Soy sauce;
Functional drinks (Tokuho);
Val-Try/Sour milk;
L. H. Lam, T. Shimamura, K. Sakaguchi, K. Noguchi, M. Ishiyama, Y. Fujimura and H. Ukeda, "Assay of angiotensin I-converting enzyme-inhibiting activity based on the detection of 3-Hydroxybutyric acid", AnalBiochem., 2007364, 104.
2) Captopril;
ACE inhibitory drinks (Tokuho);
L. H. Lam, T. Shimamura, S. Manabe, M. Ishiyama and H. Ukeda, "Assay of Angiotensin I-converting Enzyme-inhibiting Activity Based on the Detection of 3-Hydroxybutyrate with Water-soluble Tetrazolium Salt", AnalSci., 200824, 1057.
3) Captopril;
L.H. Lam, T. Shimamura, M. Ishiyama, H. Ukeda, "Flow injection analysis of angiotensin I-converting enzyme inhibitory activity with enzymatic reactors"Talanta2009, 79, 1057.
4) Plasma M. Fujita, K. Ohnishi, S. Takaoka, K. Ogawawara, R. Fukuyama, H. Nakamuta, "Antihypertensive Effects of Continuous Oral Administration of Nattokinase and Its Fragments in Spontaneously Hypertensive Rats", Biol. Pharm. Bull.2011, 34(11), 1696.
5) Edible mushrooms C. C. Lau, N. Abdullah, A. S. Shuib, "Novel angiotensin I-converting enzyme inhibitory peptides derived from an edible mushroom, Pleurotus cystidiosus O.K. Miller identified by LC-MS/MS", Altern. Med.2013, 13, 313.
6) Fermented Soybean;
Fermented milk;
K. Yamaki, "Screening Research Methods for α-glucosidase Inhibitors and Angiotensin-converting Enzyme Inhibitors in Fermented Soybean Products and Fermented Milk Products", JARQ2014, 48, 41.
7) Edible mushrooms C. C. Lau, N. Abdullah, A. Shuib, and N.Aminudin, "Novel angiotensin I-converting enzyme inhibitory peptides derived from edible mushroom Agaricus bisporus (J.E. Lange) Imbachi identified by LC-MS/MS", Food Chemistry2014, 148, 396.
8) Asparagus R. Nakabayashi, Z. Yang, T. Nishizawa, T. Mori and K. Saito, "Top-down Targeted Metabolomics Reveals a Sulfur-Containing Metabolite with Inhibitory Activity against Angiotensin-Converting Enzyme in Asparagus officinalis", J. Nat. Prod.2015, 78(5), 1179.
9) Soymilk M. Alauddin, H. Shirakawa, K. Hiwatashi, A. Shimakage, S. Takahashi, M. Shinbo and M. Komaia, "Processed soymilk effectively ameliorates blood pressure elevation in spontaneously hypertensive rats", J. Funct. Foods.2015, 14, 126.
10) water-soluble extract of cheese L. Basirico, E. Catalani, P. Morera, S. Cattaneo, M. Stuknyte, U. Bernabucci, I.De Noni, and A. Nardone, "Release of angiotensin converting enzyme-inhibitor peptides during in vitro gastrointestinal digestion of Parmigiano Reggiano PDO cheese and their absorption through an in vitro model of intestinal epithelium", J. Dairy Sci.2015, 98(11), 7595.
11) Fermented milk T. Hagi, M. Kobayashi, and M. Nomura, "Metabolome analysis of milk fermented by gamma-aminobutyric acid-producing Lactococcus lactis", J. Dairy Sci.2016, 99(2), 994.
12) Cookies N. Ontiverosa et al., "Amaranth-hydrolyzate enriched cookies reduce the systolic blood pressure in spontaneously hypertensive rats", J. Funct. Foods.2019, doi:10.1016/j.jff.2019.103613.
13) Chia seeds L.León-López et al., "Improvement of nutritional and nutraceutical value of nixtamalized maize tortillas by addition of extruded chia flour", BIOtecnia201921(3), 56.
14) Pasta E. E. Valdez-Meza et al., "Pasta Enrichment with an Amaranth Hydrolysate Affects the Overall Acceptability while Maintaining Antihypertensive Properties", Foods.2019, doi: 10.3390/foods8080282.
15) hydrolysate of Protaetia brevitarsis larva protein J. H. Lee, T. Kim, H. I. Yong, J. Y. CHa, K. Song, H. G. L, J. Je, M. Kang, Y. Choi, "Peptides inhibiting angiotensin-I-converting enzyme: Isolation from flavourzyme hydrolysate of Protaetia brevitarsis larva protein and identification"2022Food Chemistry, doi:10.1016/j.foodchem.2022.133897.


Q & A


Can ACE activity be measured with this kit?


ACE activity cannot be measured. This kit can measure ACE inhibitory activity.


What are the advantages of this kit?


Compared to the conventional method (ethyl acetate method), this method is safer, faster, and simpler in the following points.
・No organic solvent is used.
・Multiple samples can be measured at one time.
・Highly reproducible data can be obtained.


How many samples can be measured?


When samples are diluted in 6 steps to obtain IC50 (n=3), 4 samples can be measured in one 96-well microplate.
*To obtain accurate measurement values, use a plate with n=3 or higher.

<Figure below> Example of plate layout (n=3)


What substances can affect the measurement?


1. Reducing substances such as ascorbic acid will reduce the WST in Indicator solution and cause a positive error. Please keep the concentration of ascorbic acid at 0.01% or less if the samples contain it.

2. If a substance that inhibits aminoacylase or 3HBDH is present, the enzyme reaction will be affected and accurate measurement will not be possible.

3. Strongly acidic samples containing citric acid or acetic acid may precipitate components in Substrate buffer and inhibit color development. Adjust the sample to pH 5 or higher before measurement.
 (Add a small amount of sodium bicarbonate powder to neutralize, centrifuge the sample, and use the supernatant).

4) If the sample contains insoluble substances, use the filtered solution or supernatant after centrifugation as the sample.

5) For samples with strong coloration, refer to the instruction manual.


The sample I want to measure is difficult to dissolve in water. Is there a way to measure it?


Samples that are difficult to dissolve in water should be dissolved in DMSO or ethanol and then diluted with water.
We have confirmed that DMSO or ethanol does not interfere with the measurement of organic solvent concentrations up to approximately 1% in the sample.


Any examples of extraction methods and precautions?


Sample Preparation Example (Vegetables/Fruits)

・In the case of food samples, homogenize the sample, centrifuge it, and use the supernatant.

・If the sample is turbid, filter it or dilute it to make a clear solution because the turbidity affects the measurement.

・If the sample has strong coloration, dilute the solution accordingly to the extent that it does not affect the assay. Refer to the instruction manual.


Does this kit measure the inhibitory activity against ACE only, or does it react with ACE2 as well?


ACE only.
This kit does not measure ACE2 inhibitory activity.


Is there any problem if I reverse the order of dissolution of Enzyme B and Enzyme A?


This will reduce sensitivity.
Be sure to dissolve Enzyme B in DI water first, and then use that solution to dissolve Enzyme A.
